Painted Galvanised Trailers

Click images to enlarge:

Available in 12 fantastic colours, the range of painted galvanised trailers are made tough for Australian conditions. Whether you are carrying a load up the road or across the country you want to rely on the trailer you own to do the job.

Our trailers are built to last. Australian made for Australian conditions,and come with unbeatable 2 year Warranty and FREE 2 years Roadside Assist. Check out the outstanding features you get with these trailers:

  • galvanised steel construction
  • checkerplate floor
  • full chassis
  • longer drawbar
  • jockey wheel clamp
  • spare wheel bracket
  • new wheels and tyres
  • magnetic trailer plug

It doesn’t stop there though. Other features include 300mm high sides, Wear plate under springs, full rear cross member, 750kg Aggregate Trailer Mass (ATM).

Utility corner posts mean that your trailer is ready to add a cage any time you want.

When You Need it Even Tougher…

There are options available for deep sides, brakes and shackle springs as needed. Heavy duty models include full chassis with cross members around every 300mm and heavy duty ties rails all round.

Accessories such as cages, tonneau covers, tradesman’s tops, pantec tops, ladder racks, drop-in bike racks, jockey wheels and spare wheels are available on all trailers.

Specifications

Floor
Checkerplate Galvanised (Galvaneal)
Chassis
Galvanised SHS
Drawbar
75 x 50 Galvanised RHS
Body Panels
Galvanised Galvaneal) Steel
Axle(s)
39mm Diameter Solid High Tensile Steel
Hubs
150mm Cast Steel Trailer Hubs
Bearings
Standard L.M. Series Holden
Wheels & Tyres
13”/14” New Wheels & Tyres
Tie Rails
Square Tie Rails
Lights
LED
Jockey Wheel Clamp
Included
Coupling
Zinc Plated Quick Release Coupling
Springs
Slipper Springs

These trailers are available to Rent Then Buy.

Fill in your details in the enquiry form to request more information about our Rent Then Buy options.

Dimensions

Size H L1 L2 L3 W1 W2
5 x 3’6″ 450mm 1500mm 1100mm 2600mm 1050mm 1530mm
6 x 4 450mm 1800mm 1250mm 3050mm 1200mm 1680mm
7 x 4 450mm 2100mm 1340mm 3440mm 1200mm 1680mm
7 x 5 450mm 2100mm 1380mm 3480mm 1500mm 1980mm
8 x 5 450mm 2400mm 1500mm 3900mm 1500mm 1980mm
